Default 68 GTO cam specs

Just wondering if anyone has the old NHRA cam and spring specs for a 68 GTO 400/350 4 speed. I bought one to restore and thought it would be fun to build it around the old stocker specs.

Rick Ryan
JRyan is offline   Reply With Quote
Old 04-25-2013, 12:00 PM   #2
FED 387
VIP Member

Join Date: Jun 2006
Posts: 3,413
Likes: 514
Liked 329 Times in 177 Posts
Default Re: 68 GTO cam specs

try wallaceracing.com--- they race all kinds of Pontiacs has cam specs on their website might ask em about your spring questions--good luck
FED 387 is offline   Reply With Quote
Old 04-25-2013, 12:39 PM   #3
Dan Fahey
VIP Member

Dan Fahey's Avatar

Join Date: Oct 2008
Posts: 2,128
Likes: 1,084
Liked 184 Times in 113 Posts
Default Re: 68 GTO cam specs

Quote:
Originally Posted by JRyan View Post
Just wondering if anyone has the old NHRA cam and spring specs for a 68 GTO 400/350 4 speed. I bought one to restore and thought it would be fun to build it around the old stocker specs.

Rick Ryan
You can check on NHRA that has all the cam spec in the Engine section.

Pontiac did not use a lot of lift on their cams, mostly in the .401 to .421 range.
Even the RA4 was only something like .475
Dan Fahey is offline   Reply With Quote
Old 04-25-2013, 01:32 PM   #4
JRyan
Senior Member

Join Date: Apr 2003
Location: Aberdeen SD
Posts: 645
Likes: 30
Liked 112 Times in 31 Posts
Default Re: 68 GTO cam specs

NHRA has the lift specs but they don't have the duration and overlap specs which is what I'm looking for.
JRyan is offline   Reply With Quote
Old 04-25-2013, 01:35 PM   #5
71lemans
Junior Member

Join Date: Feb 2009
Posts: 35
Likes: 8
Liked 0 Times in 0 Posts
Default Re: 68 GTO cam specs

Cam number 9779067
Attached Thumbnails
Click image for larger version

Name:	1968 Pontiac cam specs.jpeg
Views:	278
Size:	175.7 KB
ID:	18674
71lemans is offline   Reply With Quote
Old 04-25-2013, 03:11 PM   #6
FED 387
VIP Member

Join Date: Jun 2006
Posts: 3,413
Likes: 514
Liked 329 Times in 177 Posts
Default Re: 68 GTO cam specs

SPECS FOR CAM # 9779067


INTAKE
Dur 273
CL 112
Rocker arm lift
1.5---.407
1.65--.447
OVERLAP 54
EXHAUST
Dur 289
CL 113
SAME ROCKER SPECS
FED 387 is offline   Reply With Quote
Old 04-25-2013, 03:17 PM   #7
JRyan
Senior Member

Join Date: Apr 2003
Location: Aberdeen SD
Posts: 645
Likes: 30
Liked 112 Times in 31 Posts
Default Re: 68 GTO cam specs

Thanks guys that's what I was looking for.
